The table below lists part of the UFOPOWER LiFePO4 cell range for medical equipment and portable devices. 1C and 3C high-discharge cells are available; custom specifications can be developed on request.
| Parameter | Specification |
|---|---|
| Battery chemistry | LiFePO4 (Lithium Iron Phosphate) pouch cell |
| Nominal voltage | 3.2V |
| Discharge rate | 1C standard; 3C high-discharge cells available |
| Cycle life | Over 2000 ~ 5000 cycles |
| Operating temperature | Wide range; optional low-temperature formula down to -40°C |
| Self-discharge | Low – retains charge when not in use |
| Safety | Stable chemistry, low risk of fire or explosion |
| Model NO. | C-Rate | Nom. Voltage | Capacity | Max. Cont. Discharge Current | Thickness (mm) | Width (mm) | Length (mm) | Weight (g) |
|---|---|---|---|---|---|---|---|---|
| UFO8218040 | 1C | 3.2V | 450mAh | 0.45A | 7.9±0.3 | 17.5±1.0 | 41.5±1.0 | 10.0±1.0 |
| UFO6230048 | 1C | 3.2V | 650mAh | 0.65A | 5.8±0.2 | 29.5±1.0 | 48.5±1.0 | 15.0±1.5 |
| UFO8329078 | 1C | 3.2V | 1600mAh | 1.6A | 8.0±0.3 | 28.0±1.0 | 76.5±1.0 | 33.0±1.5 |
| UFO8930085 | 1C | 3.2V | 2000mAh | 2A | 8.6±0.3 | 29.0±1.0 | 85.0±1.0 | 42.0±2.0 |
| UFO4163133 | 1C | 3.2V | 3000mAh | 3A | 3.9±0.2 | 63.0±1.0 | 132.5±1.0 | 64.5±2.0 |
| UFO9549092 | 1C | 3.2V | 4000mAh | 4A | 9.2±0.3 | 48.5±1.0 | 92.0±1.0 | 81.0±3.0 |
| UFO6865132 | 1C | 3.2V | 5000mAh | 5A | 6.5±0.2 | 62.5±1.0 | 129.5±1.0 | 105.0±3.0 |
| UFO8074133 | 1C | 3.2V | 7500mAh | 7.5A | 7.7±0.3 | 73.5±1.0 | 133.0±1.0 | 151.0±3.0 |
| UFO76B0136 | 1C | 3.2V | 10500mAh | 10.5A | 7.3±0.3 | 109.0±1.0 | 136.5±1.0 | 219.0±5.0 |
| UFO93C0246 | 1C | 3.2V | 25000mAh | 25A | 9.0±0.3 | 119.0±1.0 | 245.0±1.0 | 506.0±10.0 |
Note: The above table lists part of the LiFePO4 cells. 3C high-discharge cells and custom specifications are available – contact sales@ufo-battery.com for details.
Medical equipment must operate reliably without risk. LiFePO4 chemistry is among the safest lithium battery chemistries, providing the peace of mind that clinical and portable medical devices require.
Stable chemistry – more resistant to fire or explosion than other lithium-ion types
Thermal stability – performs reliably even in high-temperature environments
Stable voltage output throughout the discharge cycle for consistent device performance
Long cycle life of over 2000 ~ 5000 charge cycles
Low self-discharge – keeps backup and standby equipment ready
For portable and wearable medical devices, size and weight matter. UFOPOWER LiFePO4 pouch cells offer a thin, lightweight form factor with the option of a low-temperature formula for demanding environments.
Lighter than lead-acid batteries of the same capacity – ideal for portable equipment
Thin pouch design from 3.9 mm thickness for space-constrained devices
Optional low-temperature formula down to -40°C for outdoor and cold-chain applications
Wide operating temperature range in both cold and hot conditions
Fast charging capability without degrading longevity
UFOPOWER is a source manufacturer with physical factories, strong R&D capacity, short delivery times and sufficient stock. We provide integrated customization of LFP cells, BMS and structural design to match your medical product requirements.
Self-developed battery cells with guaranteed, non-false-labeled capacity
Custom LFP cell + BMS + structural design integrated solutions
Strict quality control: comprehensive quality system from parts to finished products
Compliant with domestic and international battery certifications
Samples and mass production available; OEM/ODM services
Complete service system with local support in China, USA and Germany
